Panasonic BL-C30A - Manual (Page 36)

Operating Instructions
36
Notes
• Some wireless devices do not support the WEP 152 bit.
• The camera supports only the open system authentication. If the router or
access point is set to shared key authentication, set it to auto or open
system.
4.
Click [Save] when finished.
• New settings are saved.
• When finished, "Success!" is displayed.
5.
Click [Go to Wireless configuration page].
• The Wireless page is displayed.
6. Set the switch to WIRELESS.
Notes
• It takes about 1 minute for the new settings to be effective.
• It is not possible to access the camera simultaneously by both wired and
wireless connection.
• To communicate using wireless connection, set up the camera by using
wired connection and set the switch from wired to wireless as shown
below.
• When you switch wired to wireless or vice versa, restart the camera. Some
routers also may need to be restarted after switching.
WIRED WIRELESS
Switch
< Bottom >
