Printing
Adjusting the pre-imprinter printing position
1.
Locate the green line ( 1 ) on the imprinter that is aligned with the " " mark ( 2 ) on the scanner where you
want to print.
2. Align the indicator ( 3 ) with the green line ( 1 ).
• The green line ( 1 ) indicates the printing position. Printing is not available in any other position.
2
1
3
Adjusting the post-imprinter printing position
1.
Move the carriage to the desired printing position, and align the indicator ( 2 ) with the " " mark ( 1 ) .
• The " " mark ( 1 ) indicates the printing position. Printing is not available in any other position.
2
1
Operating Manual 75
