3. Push in both sides of the paper feed roller cover, and pull it towards you to open.
4. Turn the roller tip ( 1 ) towards you, and remove rollers from the shaft while opening the tip.
• Remove both the paper feed rollers ( 2 ) and separation rollers ( 3 ).
2
3
1
5. Take out the new paper feed rollers and separation rollers in the optional "Roller exchange kit (KV-SS033)".
6. Align the shaft and the roller hole, and install the rollers on the shaft until they click into place.
• Install both the paper feed rollers ( 1 ) and separation rollers ( 2 ).
1
2
60 Operating Manual
Replacement Parts and Optional Units
