(Hum and noise measurements: 22 Hz to 22 kHz BW)
GENERAL SPECS:
Remote volume range: 0dB to 70dB of attenuation
Off channel attenuation: 0dB to 70dB
Mute: Channel is attenuated 45dB when Mute to ground
connection is made.
MuteBus: Multiple channels can be attenuation 45dB when MuteBus
to ground connection is made.
Status output: Status is high (5V) when channel is active. It is low (0V)
when channel is not active.
Power consumption: AC 120 Volts, 60Hz, Domestic
AC 230 Volts, 50/60 Hz Export
15 watts
Weight: 11 pounds
Dimensions: Width: 19 inches
Depth: 9 1/4 inches
Height: 3 1/2 inches
10
Output Residual Noise S/N Ratio Test Conditions
Ref: 0 dBu Ref: 2:21 dBu
Main Out -85dBu 87dB All controls down
-84dBu 86dB One channel nominal,
Master level nominal
-85dBu 87dB All controls down
Aux Out
-80dBu 82dB One channel send
nominal,Monitor master
nominal
AUTOMIX ª 2 SPECIFICATIONS
Hum and Noise:
