Prince Castle 630-ROM4 User Manual

Page 4

background image

Romar Pasta Cooker
630-ROM4

Pasta Dispensers

1

2

The Pasta Dispenser assembly is composed of
three removable parts: one hopper, one hopper
cover and one loading box. No tools are needed to
assemble these parts.

The Pasta Dispenser is a precision machine and
should be handled with care.

Lift the cover from the Pasta Dispenser assembly and
slide the cover down inside the loading box as shown.

A. Fill loading box with approx. 1 lb. of long-cut

pasta.

B. Fill hoper with up to 14 lbs. of the same long-cut

pasta.

Use only pasta recommended by Prince Castle.
Using other types of pasta or food may cause
severe damage and void all warranties and
maintenance contracts.

3

4

A. Remove the loading box cover, allowing pasta to

fall into the hopper.

B. Place loading box cover firmly on top of loading

box.

The long-cut Pasta Dispenser is now ready for use.

It is recommended that you keep the hopper
supplied with at least two pounds of pasta at all
times.

Fill each of the two short-cut past dispensers with up
to 14 lbs. of pasta.
The short-cut Pasta Dispensers are now ready for use.

Procedure Complete

Loading

Box

Loading

Box

Cover

Loading

Box

Hopper

Loading

Box

Cover

Printed in USA 0404 © 2004

4

630-500
