FEATURES AND CONTROLS
1. Hood
2. Headlight
3. Windshield
4. Handlebar
5. Operator Seat
6. Passenger Hand Hold Strap
7. Cargo Rack
8. Taillights
9. Snow Flap
10. Track
11. Suspension
12. Trailing Arm
13. Nosepan
14. Front Bumper (do not use for pulling or dragging the snowmobile)
15. Skis
Cargo Rack
Always secure cargo before operating. Do not exceed the rack weight
limit specified on the cargo rack decal. Do not allow a passenger to sit
on the seat back or the cargo rack.
14
1
2
3
4
5
6
8
9
11
10
12
15
13
7
