Know Your Grass Catcher
READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE ASSEMBLING OR OPERATING YOUR GRASS CATCH ER.
Compare the illustrations with the carton contents to familiarize yourself with the parts before starting the assembly. Study
the operating instructions and safety precautions thoroughly to insure proper functioning of your Grass Catcher and to
prevent injury to yourself and others. Save this manual for future reference.
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in
severe eye damage. Always wear safety glasses or eye shields be fore starting your trac tor and
while mow ing. We recommend a wide vision safety mask for over the spec tacles or stan dard safety
glasses.
UNPACKING INSTRUCTIONS
• Remove all parts and packing materials from carton.
• Check carton contents against list. Be sure all parts
are there.
CARTON CON TENTS:
(2) Container Tops
(2) Container Bottoms
(1) Upper Chute
(1) Lower Chute (1) Support Assembly
(1) Bag of Parts
(1) Owner's Manual
00155
GROUP "A"
ASSEMBLY
LOCATION
HARDWARE SHOWN ACTUAL SIZE
BAG OF PARTS CONTENTS
GROUP "C"
REAR
MOUNTING
BRACKET
TO
DRAW BAR
(4) Shoulder Bolts
5/16 - 18 Self Tapping
GROUP "B"
(1) Locknut 3/8-16 (1) Bolt 3/8-16 x 1-1/4
MOWER
DECK
BAFFLE
(1) Wing Nut (1) Washer 13/32 x 1 x 16 Ga.
LOWER
CHUTE
TO
MOWER
DECK
TOOLS REQUIRED FOR ASSEMBLY
(2) 9/16" Wrenches
