Peg-Perego Pliko X-Lite - Manual (Page 12)

the zip-on rain canopy or mosquito netting (see
Accessories Line).
10• To mount the hood, push the fittings down until
they click, as shown in the figure.
11• As shown in the figure, button the hood inside the
armrest and the backrest of the stroller.
12• To stretch out the hood, push the coupling
downward. The hood can be reclined by following
the inclination of the backrest.
13• To remove the hood, you must unbutton it from
the stroller, loosen the couplings and raise the
tabs of the fasteners, pushing towards the inside
of the stroller.
BRAKE
14• To apply the brakes, push down with one foot the
bars on the rear wheels, as shown in the figure.
To release the brakes, draw the bar up. Always set
the brakes on the stroller when it is not in motion.
SAFETY BELT
15• A: Make sure that the brace is properly inserted by
pushing as shown in the figure. B: Fasten the belt
as shown in the figure.
16• To unfasten the belt, press on the buckle sides
and pull out the waist strap.
ADJUSTING THE FOOTBOARD
17• The footboard can be adjusted to three different
positions. To lower the footboard, pull the two
small levers downward while lowering. To lift the
footboard, pull it up until it clicks into place.
ADJUSTING THE BACKREST
18• The backrest can be lowered to three different
positions. To lower the backrest, pull the two
adjustment levers towards you. To raise it, pull the
backrest upwards.
SWIVELLING WHEELS
19• To make the front wheels swivel, push down as
shown in the figure. To fix the wheels, pull up the
lever.
CLOSING
Before closing the stroller, loosen the braces if
the hood is attached, and raise the backrest if it is
lowered.
20• The stroller can be closed with one hand: pull first
one lever up and then the other until it releases.
21• Grip the central handle and pull it upward until it
closes, as shown in the figure.
22• Verify the correct closing of the stroller from the
safety hook. The folded stroller can stand upright.
TRANSPORT
23• The stroller can easily be carried (lock the
swivelling front wheels) by gripping the central
handle, as shown in the figure.
24• You can also use the side handle to carry it, as
shown in the figure.
REMOVABLE LINING
25• To remove the lining from the stroller, slip the
leg divider off the safety belt from under the seat.
Loosen the fabric sack buttons from the seat, and
slip the sack off the hooks on the footboard.
26• Slip the safety belt buckles off the back of the
backrest, and remove the straps from the two
shoulder fasteners.
27• The shoulder fasteners are attached to each
other. To remove them, slip them out through
the openings in the fabric sack, as shown in the
figure.
28• Loosen the buttons on the side of the fabric sack,
as shown in the figure.
29• Loosen the safety belt on one side only, as shown
in the figure, holding your finger under the nut.
Slip the loosened safety belt off the stroller
through the opening in the fabric sack, as shown
in the figure.
• To remount the fabric sack on the stroller, follow
the directions given above in the reverse order,
making sure to fasten the safety belt properly.
GANCIOMATIC SYSTEM
The Ganciomatic System is the swift, practical
system that allows one to fasten to the stroller, with
Ganciomatic fasteners, the car seat Primo Viaggio,
which can be bought separately and is also equipped
with Ganciomatic System. Primo Viaggio can be
detached from its base (which stays in the car) and
attached to the Ganciomatic fasteners of the stroller to
transport your child without disturbing him/her.
STROLLER GANCIOMATIC HOOKS
30• To raise the Ganciomatic hooks on the stroller,
pull the sack up at the corners of the seat and
turn the two hooks upwards until they click into
place.
31• To lower the Ganciomatic hooks on the stroller,
pull the little lever outwards and turn the hooks
upwards at the same time, as shown in the figure.
PLIKO X-LITE + PRIMO VIAGGIO
32• To fasten the car seat to the stroller:
- set the brake on the stroller;
- remove the hood from the stroller;
- completely lower the backrest on the stroller;
- lift the footboard on the stroller to the highest
position;
- raise the Ganciomatic hooks on the stroller;
- turn the child car seat towards the backrest on the
stroller, lining up the front hooks on the car seat
with the hooks on the stroller. Push the car seat
downwards until it clicks into place.
• See the userʼs manual for instructions on how to
detach the car seat from the stroller.
ACCESSORY LINE
33• Diaper-Changing Bag: Satchel with pad for
changing babyʼs diaper. Attaches to the stroller.
34• Rain Canopy: Rain canopy zips onto the hood.
35• Mosquito Netting: Mosquito netting zips onto the
hood.
36• Travel Bag: Practical duffle bag for transporting
the stroller by plane.
CLEANING & MAINTENANCE
Your product requires only minimal maintenance.
Cleaning and maintenance operations must be
performed only by adults.
• Be sure to keep all moving parts clean, lubricating
them with light oil if necessary.
• Dry off metal parts to prevent rusting.
• Regularly clean the plastic parts with a damp cloth.
Do not use solvents or similar products.
• Brush the fabric parts to remove dust.
• Remove any dust and sand from the wheels.
• Protect the product against smog, water, rain and
snow. Continued and extended exposure to sunlight
can change the colours of many materials.
• Store the product in a dry area.
• To wash the sack, follow the instructions below.
