17
GB
Amplifier
22W RMS per channel power output (into 4 Ohms)
15 Hz to 35 kHz frequency response
Dynamic Virtual Sub Technology™ provides a variable bass boost relative to
volume
Bass and treble tone control
CD player
CD-R and CD-RW playback compatible
Support for CD Text and 20 track audio CD playlist
Multiple playback modes (repeat, shuffle, etc.)
MP3 playback, including support for ID3 tags and M3U playlists
DAB
PURE ReVu™ enables pause and rewind of live DAB digital radio
Full Band III (174 - 240 MHz) reception. Fully compliant with ETS 300 401
and capable of decoding all DAB transmission modes 1-4
Fast autotune feature
DPAC II™ provides a more natural sound from DAB transmissions
FM
Supports RDS and RadioText
Tune by RDS station name
87.5 - 108 MHz frequency range
Speakers (optional)
6 Ohms (nominal) impedance
30W RMS power handling
Twin 3” custom designed full range drive units
Neodymium magnets
Phase correction plugs
Bass reflex ported
Connectors
3.5 mm headphone output
RF F-connector 75 Ohms for DAB aerial connection
Dual phono for external line level audio input
Dual phono for stereo analogue audio output or connection to a subwoofer
Optical Toslink connector for digital S/PDIF output (IEC958 @ 48 kHz)
USB connector for future software upgrades
Stereo spring-clip terminals for speakers
General
Fully featured remote control
Compliant with the EMC and Low Voltage Directives (89/336/EEC and 73/
23/EEC)
Main unit dimensions (excluding controls) 210 (w) x 155 (h) x 215 mm (d)
Speaker dimensions 105 (w) x 215 (h) x 215 mm (d) (where included)
2 x 3m speaker cable supplied
UK and Euro Mains cables supplied
Bootlace aerial supplied
Telephone support hotline and internet website
Two year warranty
Technical specifications
