Professor RGM-3000/REB-3000
GPS Module Operational Manual)
17
Recommanded REB-3000 Antenna Ground Plate
Connector tool (Option, not included in standard kit)
It is used to remove or install FPC on connector.
Software interface
NMEA V2.2 Protocol
It is the RS-232 interface:9600 bps, 8 bit
data, 1 stop bit and no parity. It supports the
following NMEA-0183 messages:GGA, GLL,
GSA, GSV, RMC and VTG.
NMEA Output Messages
The Engine board outputs the following
messages as shown in Table 1:
Table 1 NMEA-0183 Output Messages
NMEA Record Description
GGA Global positioning system fixed data
GLL Geographic position – latitude / longitude
GSA GNSS DOP and active satellites
GSV GNSS satellites in view
RMC Recommended minimum specific GNSS data
VTG Course over ground and ground speed
