Page 6
6
WIRING CONNECTION
FRONT Lch
SPEAKER
GREEN
GREEN/BLACK
MEMORY
BACK-UP
MAIN UNIT
Rch RED
Lch WHITE
AUX IN
IGNITION
SWITCH (B+)
POWER
ANTENNA
RED
GROUND (B–)
YELLOW
BLACK
BLUE
REAR RCA CABLE
(YELLOW)
ANTENNA SOCKET
(GREY)
Rch RED
Lch WHITE
WHITE
WHITE/BLACK
REAR Lch
SPEAKER
CD CHANGER
CONNECTOR
SOCKET
(BLACK)
VIOLET
VIOLET/BLACK
GREY
GREY/BLACK
FRONT Rch
SPEAKER
REAR Rch
SPEAKER
WIRING
REMOTE
CONNECTOR
SOCKET
(BLACK)
