P93 Options
ProActive service – additional year(s) plan description
Ī 7x24 corrective maintenance coverage
Ī 7x24 annual performance check
Ī Annual power protection audit
Ī 7x24 remote monitoring advance response
Ī Monthly UPS performance report with web access to account information and site service activity
Powerware IBM IBM Per P93
Part Number Feature Code Part Number Minimum Maximum
Concurrent with UPS purchase 155102012-001 7001 97P2657 0 4
Non-concurrent to UPS purchase 155102013-001 7002 97P2658 0 4
Connectivity
ConnectUPS X-Slot Web/SNMP/xHub card (10/100Mb)
The ConnectUPS-X Web/SNMP/xHub card provides real-time UPS monitoring and control of power throughout both 100Mb and 10Mb networks. When used
in conjunction with NetWatch Client software, it also provides graceful shutdown of the operating system of up to 255 computers powered by a single UPS.
The advanced features of the ConnectUPS-X include:
Ī Real-time, enterprise-wide monitoring provides valuable information for analysis of critical power conditions and problem identification
Ī Supports 100Mb and 10Mb Ethernet networks
Ī Built-in three ports switching hub adds three 10/100Mb network connections with no additional expense
Ī Monitoring via Web using computer (through standard Web Browsers, e.g. Internet Explorer and Netscape). PDA or cell phone provides easy, anywhere,
anytime access
Ī Monitoring via SNMP using Network Management Software packages (e.g. Tivoli, CA Unicenter and HP Openview)
Ī Analysis of chronic power problems and determination of trends through data logging and sophisticated graphic tools
ConnectUPS MultiServer Card
The ConnectUPS MultiServer card is an X-Slot connectivity device that provides serial connection to up to five computers for unattended, graceful shutdown
and power monitoring. The card operates in conjunction with LanSafe software (included with UPS). The advanced features of the MultiServer card include:
Ī Real-time monitoring of critical power parameters
Ī Graceful, unattended shutdown of multiple computers
Ī Maximizes uptime of more critical loads through operation in tandem with load segment feature of UPS
Ī Supports simple signaling (relay contacts) through additional DB-9 port
Relay Interface Card
The Powerware Relay Interface card is an X-Slot connectivity device that provides monitoring of UPS status through isolated, dry contact, Form-C relays.
It also provides the interface for AS/400 computers as well as many industrial applications. The advanced features of the Relay Interface card include:
Ī Isolated, dry contact, Form-C relays for “utility failure”, “low battery”, “UPS alarm /OK” or “on bypass”
Ī User-selectable “normally open” or “normally closed” contacts
Ī Remote shutdown of UPS through integrated shutdown function
Ī Hot-swappable – UPS maintains power to critical applications while changing cards
Powerware IBM IBM Per P93
Part Number Feature Code Part Number Minimum Maximum
ConnectUPS X-Slot Web/SNMP card 103002974-5501 2934 53P4619 0 2*
ConnectUPS X-Slot MultiServer card 05146447-3901 2933 04N7027 0 2*
ConnectUPS Relay Interface card & cable 103003564 2936 97P3886 0 2*
*Maximum combination of FC 2933, 2934, 2936 and other ConnectUPS X-Slot card options is two. ConnectUPS cards are installed onsite and concurrently with P93 startup by
Powerware Service Technician. Customer responsible for software installation.
Output connections
Three (3) NEMA non or locking receptacles (outlets) with breakers and connectors. Each connector shall be on a cord with maximum length of 50 feet.
Choose from:
pSeries pSeries zSeries
Feature Code IBM Plug Type iSeries Feature Code Part Number Feature Code Part Number
5-15R duplex 4 1412, 1413, 2960 + 9082 86G7648 9800 31L7061, 2, 4
5-20R duplex - - - - -
L5-15R 7 2960 + 9083, + 9082 - - 31L7067, 8
L5-20R - - - - -
L5-30R - - - - -
6-15R 5 1410, 1403, 1411, 1451, 1452, 1457, 2961 & 9082 183576, 4, 3 9909, 9833 -
L6-15R 10 1414, 1416, 1453, 1454, 1458 186G7878, 9 - 31L7070, 1
6-20R 29 1400, 1401, 1423 - - -
L6-20R 11 1404, 1406, 1428 - - -
L6-30R 12 1424, 1426 11F0113, 4 - -
Powerware IBM IBM Per P93
Part Number Feature Code Part Number Minimum Maximum
Output power cords (NEMA) 103003673 9881 97P2660 0 6*
*Hardware installed onsite and concurrent to P93 installation.
