Function Minimum Load Z Output Level Bal./Unbal. Connector
(Ohms)
Nominal Max.
Main L/R 600 0 dBu +22 dBu Unbal. 1/4" Phono
Monitor
+4 dBu +26 dBu Bal XLR: Pin 1 Gnd,
Pin 2 (+),
Pin 3 (-) (Bal)
Channel 600 0 dBu +22 dBu Unbal. 1/4" TRS: Tip Send,
Insert Send Ring Return,
Sleeve Ground
Wedge 600 0 dBu +22 dBu Unbal. 1/4" Phone
Headphone 8 0 dBu +22 dBu Unbal. 1/4" TRS: Tip Left,
(no load) Ring Right,
Sleeve Ground
Output Residual Noise S/N Ratio Test Conditions
Ref: 0 dBu
Monitor -97 dBu 97 dB All faders down
-90 dBu 90 dB Master fader nominal,
All channels muted
-84 dBu 84 dB All controls nominal,
mic gain min
Left/Right -97 dBu 97 dB All fader down
-90 dBu 90 dB Master gader nominal,
Channel faders down,
All channels muted
-84dBu -84 dB All controls nominal,
mic gain min
15
RQ ™ 1606M Output Specifications:
RQ ™ 1606M Hum and Noise:
(Hum and Noise Measurements: 22 Hz to 22 kHz BW)
0 dBu = 0.775V (RMS)
Specifications subject to change without notice.
