APPENDIX D
INTERFACE PIN ASSIGNMENT
DDS/CLEAR CHANNEL INTERFACE
The DDS/Clear Channel Interface is an RJ-48S modular jack.
Pin # Signal
1 TX+
2 TX-
3 no connection
4 no connection
5 no connection
6 no connection
7 RX+
8 RX-
MODEL 2450/C
M/34 CONNECTOR (V.35), TERMINAL INTERFACE
Pin # Signal
A Frame Ground
B SGND (Signal Ground)
C RTS
D CTS
E DSR
F CD
L LL (Local Loop)
M TM (Test Mode)
N RL (Remote Loop)
P TD
R RD
S TD/
T RD/
U XTC
V RC
W XTC/
X RC/
Y TC
AA TC/
APPENDIX C
FACTORY REPLACEMENT PARTS
AND ACCESSORIES
Patton Model # Description
2450/A .............................56/64 kbps CSU/DSU (RS-232. DB-25
female connector)
2450/B .............................56/64 kbps CSU/DSU (RS-422/530,
DB-25 female connector)
2450/C.............................56/64 kbps CSU/DSU (V.35, M/34
female connector)
2450/E .............................56/64 kbps CSU/DSU (V.35, DB-25
female connector)
10-2500 ...........................DDS Cable, RJ48S - RJ48S, 6 foot
080510 ACB ....................120V Wall Mount AC Adapter
080512 ACIB ...................230V AC adapter (No Power Cord)
0805US ...........................American Power Cord
0805EUR.........................European Power Cord CEE 7
0805EURP ......................Europlug Power Cord CEE 7/16
0805UK ...........................United Kingdom Power Cord
0805AUS .........................Australia/New Zealand Power Cord
0805DEN.........................Denmark Power Cord
0805FR............................France/Belgium Power Cord
0805IN.............................India Power Cord
0805IS .............................Israel Power Cord
0805JAP..........................Japan Power Cord
0805SW...........................Switzerland Power Cord
