Page 10

background image

2

PowerScan

®

RF Scanner

Installing the

Battery

Orient the battery as shown in Figure 1, then push it into the scanner
until it snaps in place. To remove the battery, push in on the release tabs
on both sides of the battery’s base and pull it straight out of the scan-
ner.

Figure 1. Installing the Battery

NOTE

To assure maximum usage, batteries should always
be fully charged before their initial use. (See “Bat-
tery Charging and Maintenance” on page 8.)

1.

Battery Release Tabs

1

1
