6
1 A UTO
Auto matically search the singl e source wh en power on.
2 CD /D VD
CD /D VD
17 BASS
18/21 L/ R
19 SPEAKER
S peaker A/B/A+B S elector
20/23 VOL+ VOL-
、
、
、
、
、
、
、
、
S elector.
3 A UX/USB
O ther single source or USB Selector.
4 TUNER
TUNER Selecto r.
5 LOUD
Pre ss the but ton to correct an unbalance p rog ram source .
6 I POD/MP3
I POD/MP3 Selector
7 A UTO SCAN
AM/FM aut o scan selector sca n and store stations
automic all y. Can st ore 5 0 st ations.
8 MEMO RY
Aft er a stati on has been found yo u can store t he station
by press ing the ME MORY bu tton,and the screen will
display SAVE.
9 ST/MON O
Stereo and mono selector.
10 FM/PAUSE
Muti-functional key
it is FM sel ector when it isTUNER
and it means PAUSE w hen you use USB.
11 AM/PLAY
Muti-functional key
it is AM selector when it is TUNER,
and it means PLAY when you use USB.
12/13 PREV> NEXT<
S tation p review a nd n ext selector.wh en you play USB,it
means preview song or next song.
14/15 TUNING> TUNING<
T he two keys are used to adjust to the best s ingle of
the stations .
16 TRE BLE
Mas ter Treb le Up An d Down
Mas ter Bas s Up And Down
Left / Right Balance Con trol
Master Vo lume Up And Down
22 M UTE
Mu te Selec tor
、
、
、
、
、
，
、
，
、
、
， ，
、
、
、
、
（ ）
，
Remote Controller Operation
1. Remote controller should be operated within 6
meter and the scope of 30 in front of receiver.
2. Make sure that there is no big obstacle between
remote controller and machine.
3. Remote sensor should be far away
from the light,high amounts of light can affect its performance.
5
(3) REC.LINE OUTPUT JACKS
(2) AUDIO INPUT JACKS
(1)TUNER ANT
(4) PRE OUTPUT JACKS
(5) SUB-WOOFER OUTPUT JACKS 1&2
Connect the audio ouput jacks of
DVD/CD
AUX to these jacks. 、
Connect for AM and FM antennas.
Connect the RECORD input jacks to
these jacks.
Connect the professional input jacks
to these jacks.
(8) B SPEAKER OUTPUT TERMINALS
(7) A SPEAKER OUTPUT TERMINALS
(10) 110V/220V SWITCH
(9) COOLING FAN
(11) POWER CORD
(6) WIRELESS MICROPHONE ANTENNA
Connect your the other speaker system(s) to
these terminals.
Connect your speaker system to
these terminals.
According to power voltage ,push this button
to the station of the110V or 220V.
Connect to AC 110V/60Hz&220V/50Hz outlet.
1 2 3 4 5 6 7 8 9 10
WA RNI N G
11
