Polaris FS IQ Touring - Manual (Page 126)

123
MAINTENANCE
Electrical System
RELAY LABEL FUSE LABEL ITEM POWERED
START SOLENOID
RELAY
Ground side of start solenoid
CHASSIS
RELAY
SPARE 20A None
ACCESSORY
EMERGENCY
SPARE 30A
Accessory plugs
CHASSIS
30A
High beams
Low beams
Handwarmers
Thumbwarmer
Tail lamp
Brake lamp
Alternator coils
EFI
RELAY
EX. SENSOR
GAUGE 20A
REVERSE SHIFT
Exhaust sensor
Gauge
Reverse shift
Accessory projector beam relay
Diagnostic plug
IGNITION 20A Ignition relay power
EFI
20A
Cam phase sensor
ECU hold-on power
Reverse limit switch
Forward limit switch
Start relay coil
Chassis relay coil
Ignition relay coil
Fuel pump relay coil
Fan relay coil
Fuel pump relay power
PTO injector
MAG injector
Wastegate
IGNITION RELAY PTO ignition coil
MAG ignition coil
FUEL PUMP RELAY Fuel pump
FAN RELAY CAC fan
