VQT1S36 114
Connecting to other equipment
∫ Connection in the PTP mode (Windows R XP, Windows Vista R and Mac OS X only)
Set [USB MODE] to [PictBridge(PTP)].
Data can now be read only from the card into the PC.
• When there are 1000 or more pictures on a card, the pictures may not be imported in the PTP
mode.
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to
be printed out and instruct that printing be started on the camera’s LCD monitor.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures in the built-in memory.
Perform the print quality and other settings at the printer before printing the pictures.
Connect the camera to a printer via the USB connection cable A
(supplied).
Press 3/4 to select [PictBridge(PTP)], and then
press [MENU/SET].
Note
• Do not use any other USB connection cables except the supplied one.
Use of cables other than the supplied USB connection cable may cause
malfunction.
A USB connection cable (supplied)
• Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may be bent out of shape which will cause trouble.)
B Align the marks, and insert.
C AC adaptor (DMW-AC7PP; optional)
• Use a battery with a sufficient battery power or the AC adaptor (DMW-AC7PP; optional). If the
remaining battery power becomes low during USB connection, the alarm beeps. If this happens
during printing, stop printing at once. If not printing, disconnect the USB connection cable.
• When the camera is connected to the printer, the cable disconnect prohibit icon [å] appears.
Do not disconnect the USB cable while [å] is displayed.



