27 For more infor mation visit our web site at http://www.polkaudio.com
POLK AUDIO LIMITED WARRANTY
“Polk Audio”, “Polk”, and “Dynamic Balance” are trademarks of Britannia Investment Corporation used under license by
Polk Audio Incorporated.
Dolby, Pro Logic, Dolby Digital and AC-3 are trademarks of Dolby Laboratories Licensing Corp.
DTS is a registered trademark of Digital Theater Systems.
Polk Audio, Inc. warrants to the original pur-
chaser only that this Polk Audio Loudspeaker
Product (the “Product”) will be free from
defects in materials and workmanship for a
period of five (5) years from the date of origi-
nal retail purchase from a Polk Audio
Authorized Dealer. However, this Warranty
will automatically terminate prior to the expi-
ration of the five (5) years if the original
retail purchaser sells or otherwise transfers
the Product to any other party. The original
retail purchaser shall hereinafter be referred
to as “you.” To allow Polk Audio to offer the
best possible warranty service, please fill out
the Product Registration Card(s) and send it
to the Factory, at the address provided on the
Product Cards(s) within ten (10) days of the
date of purchase.
Defective Products must be shipped, together
with proof of purchase, prepaid insured to the
Polk Audio Authorized Dealer from whom you
purchased the Product, or to the Factory at
2550 Britannia Boulevard, Suite D, San
Diego, California 92173. Products must be
shipped in the original shipping container or
its equivalent; in any case the risk of loss or
damage in transit is to be borne by you. If
upon examination at the Factory or Polk
Audio Authorized Dealer it is determined that
the unit was defective in materials or work-
manship at any time during this Warranty
period, Polk Audio or the Polk Audio
Authorized Dealer will, at its option, repair or
replace this Product at no additional charge,
except as set forth below. All replaced parts
and Products become the property of Polk
Audio. Products replaced or repaired under
this warranty will be returned to you, within a
reasonable time, freight prepaid.
This warranty does not include service or
parts to repair damage caused by accident,
disaster, misuse, abuse, negligence, inade-
quate packing or shipping procedures, com-
mercial use, voltage inputs in excess of the
rated maximum of the unit, cosmetic appear-
ance of cabinetry not directly attributable to
defect in materials or workmanship, or ser-
vice, repair, or modification of the Product
which has not been authorized or approved by
Polk Audio. This warranty shall terminate if
the Serial number on the Product has been
removed, tampered with or defaced.
This warranty is in lieu of all other expressed
Warranties. If this Product is defective in
materials or workmanship as warranted
above, your sole remedy shall be repair or
replacement as provided above. In no event
will Polk Audio, Inc. be liable to you for any
incidental or consequential damages arising
out of the use or inability to use the Product,
even if Polk Audio, Inc. or a Polk Audio
Authorized Dealer has been advised of the
possibility of such damages, or for any claim
by any other party. Some states do not allow
the exclusion or limitation of consequential
damages, so the above limitation and exclu-
sion may not apply to you.
All implied warranties on this Product are
limited to the duration of this expressed
Warranty. Some states do not allow limitation
on how long an implied Warranty lasts, so the
above limitations may not apply to you. This
Warranty gives you specific legal rights, and
you also may have other rights which vary
from state to state.
This Warranty applies only to Products pur-
chased in the United States of America, its
possessions, and U.S. and NATO armed forces
exchanges and audio clubs. The Warranty
terms and conditions applicable to Products
purchased in other countries are available
from the Polk Audio Authorized Distributors in
such countries.
ENGLISH ESPAÑOL
26
SPECIFICATIONS
Driver Complement:
2x 1"(25mm) Dynamic Balance ® dome tweeters
2x 6 1/2"(165mm) Dynamic Balance drivers
Overall Frequency Response:
40Hz - 26kHz
-3dB Limits:
50Hz - 25kHz
Crossover Topology:
2nd Order Low Pass Filter @2 kHz
2nd Order High Pass Filter @2 kHz Mylar film capacitors
used throughout
Impedance:
compatible with 8 ohm outputs
Recommended Amplification:
20 - 250 WRMS
Efficiency (1M, 1Watt):
90dB
Available Finishes:
Black or Rosewood Finish Wood Veneer
Dimensions:
11 1/4"W x 19 13/16"H x 9 3/4"D
28.6cm W x 50.3cm H x 24.8cm D
Includes depth of wall mount brackets
Shipping Weight:
55lbs / 25kgs
ESPECIFICACIONES
Complemento del Driver:
2 x 1" (25 mm) tweeters de domo Dynamic Balance
2 x 6 1/2" (165 mm) drivers Dynamic Balance
Respuesta Total de Frecuencias:
40 Hz - 26 kHz
-3dB Límites:
50 Hz - 25 kHz
Topología de Crossover:
2o Orden Filtro de Paso Bajo @2 kHz
2o Orden Filtro de Paso Alto @2 kHz Capacitadores de
película mylar usados exclusivamente
Impedancia Nominal:
compatible con salidas de 8 ohms
Amplificación Recomendada:
20 - 250 WRMS
Eficiencia (1M, 1 Watt):
90 dB
Acabados Disponibles:
Revestimiento de Madera Negro o Palisandro
Dimensiones:
11 1/4" Ancho x 19 13/16" Altura x 9 3/4" Profundidad
28.6 cm Ancho x 50.3 cm Altura x 24.8 cm Profundidad
Incluye la profundidad de los brazos para instalación
sobre la pared
Peso de Embarque:
55 libras / 25 kg.
FRANÇAIS DEUTSCH
SPÉCIFICATIONS
Composantes:
2 x Tweeters à dôme Dynamic Balance de 1 po (25mm)
2 x Transducteurs Dynamic Balance de 6 1/2 po (165mm)
Réponse en fréquence effective:
40Hz - 26kHz
Limites -3dB:
50Hz - 25kHz
Séparation de fréquences Topologie:
Filtre passe-bas 2è ordre à 2kHz
Filtre passe-haut 2è ordre à 2Hz. Capaciteurs à pellicule
mylar seulement.
Impédance Nominale:
compatible avec sorties de 8 ohm
Amplification recommandée:
20 - 250 WRMS
Efficacité (1M, 1 Watt):
90dB
Finis disponibles :
Noir ou placage de bois de rose
Dimensions:
11 1/4"l x 19 13/16"h x 9 3/4"p
28.6cm l x 50.3cm h x 24.8cm p
incluant l’épaisseur des supports muraux
Poids:
55 lb / 25 kg
SPEZIFIKATIONEN
Bestückung:
2 x 1" (25 mm) Dynamic Balance Dome Tweeter
2 x 6 1/2" (165 mm) Dynamic Balance Töner
Frequenzgang über alles:
40Hz – 26 kHz
Frequenzgang – 3 dB:
50 Hz – 25 kHz
Topologie/Spezifikationen Frequenzweiche:
Mittel-/Hochtonmodul:
Tiefpassfilter 2. Ordnung 2kHz;
Hochpassfilter 2. Ordnung 2 kHz. Mylar Kondensatoren
durchgängig verwendet
Nenn-Impedanz:
kompatibel mit 8 Ohm Ausgang.
Empfohlene Verstärkerleistung:
20 – 250 Watt pro Kanal
Empfindlichkeit (1 M, 1 Watt):
90 dB
Gehäuseoberflächen:
schwarz oder Rosenholz Echtholzfurnier
Gehäuseabmessungen:
H x B x T: 28,6 x 50,3 x 24,8 cm
einschließlich Wandbefestigungsklammern
Gewicht incl. Verpackung:
25 kg
