31
Control
1) Power selection: EXT, OFF, CCU
2) USER SEL:
Functions specified by menu items
can be allocated to the switch.
3) RET A/B selection: For selecting the return signal
4) Front tally selection: Front tally HIGH, LOW, OFF (VF unit)
5) Viewfinder marker
selection: Center marker, safety zone, 4:3 marker
6) Gain selection: LOW, MID, HIGH
7) Output selection: CAM, BAR, TEST
8) White balance mode: A, B, preset
9) Shutter speed
selection: 1/100, 1/125 1/250, 1/500, 1/1000,
1/2000
10) AWB, ABB settings
11) Menu selection
12) CALL SW
13) INCOM:
MIC ON/OFF, receive or PGM level
14) MIC setting: MIC power, MIC gain, MIC1 selection
15) Optical filter setting: REM, LOCAL selection and LOCAL
setting
*When the CCU is connected, the selection functions for 6) to 10)
are not effective.
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
O perating temperature
range: 32F to 104F (0C to +40C)
S torage temperature
range: –4F to 140F (–20C to +60C)
O perating ambient
humidity: Less than 85%
Weight: Approx. 10.7 lbs (4.85 kg)
Dimensions: 5 (W)11-1/16 (H)14-3/8 (D) inch
(excluding protrusions)
126  280  365 mm
Basic items
1) Pickup device: 2/3 million pixel ITCCD  3
2) System: GBR pickup system
3) Color separation
optical system: f/1.4 prism
4) Optical filters: CC: 3200K, 4300K, 6300K, Cross
Diffusion
ND: CAP, Through, 1/4, 1/16, 1/64
5) Lens mount: Bayonet type
6) Output standard: SMPTE 296M/274M
7) Sensitivity:
f/10.0, 2000 lux, 3200 K, white
reflectance 89.9%
8) Horizontal modulation: More than 45% (27.5 MHz)
9) S/N ratio:
54 dB (Y: 30 MHz)
10) Horizontal frequency: 44.955 kHz, 750-line frame
/33.716 kHz, 1125 line frame
11) Vertical frequency: 59.94 Hz, progressive
/59.94 Hz, interlace
Input/output signals
1) Mic input: –20, –30, –40, –50, –60 dBm
(XLR 3-pin female2)
Gain selected by switch
2) INCOM: 0 dBm/600 ohms
(XLR 5-pin, female2)
(Mixing is controlled separately for
PGM1 and PGM2.)
3) Monitor output: HD signals = 1Vp-p, 75 ohms (BNC)
Output signals can be selected using
the monitor output selector switch.
4) QTV output: VBS signal = 1 Vp-p, 75 ohms (BNC)
5) G/L input: 1 BNC connector (tri-level SYNC)
6) AUX output: VBS signal = 1 Vp-p, 75 ohms (BNC)
(when optional unit has been installed)
Power supply:
DC 12 V (when external power is supplied)
AC 150 V–240 V (when CCU is connected)
Power consumption:
33 W (during external power supply operation)
43 W (when CCU is connected)
indicates safety information.
Specifications
