Panasonic AK-HC931BP - Manual (Page 15)

15
1
Open the microphone holder.
2
Mount the microphone and tighten up the clamp screw.
3
Connect the microphone cable to the MIC IN connector
on the camera.
When the microphone is mounted on the
viewfinder (optional accessory) for use
The microphone of the microphone kit AJ-MC700P (optional
accessory) can be mounted on the viewfinder.
MIC IN connector
Microphone
holder
Clamp screw
4
If the audio channel whose signals are to be recorded so
requires, set the AUDIO IN switch to F.
AUDIO IN switch
Connecting the microphone
