19
APPENDIX D
DISTANCE CHART, BASED ON 24 AWG (0.5 MM)
Note The actual distance and link performance may vary depending
on the environment and type/gauge of wire used.
Note DS = downstream, US = upstream
Line Rate
Distance in feet
(km)
Throughput
at Max Distance
(bits per second)
4/1 4250 ft
(1.3 km)
4,629,408 (DS)
1,175,328 (US)
9/1 4250 ft
(1.3 km)
10,364,256 (DS)
1,176,000 (US)
16/2 3500 ft
(1.0 km)
18,374,496 (DS)
2,351,328 (US)
6/6 4000 ft
(1.2 km)
6,908,832 (DS)
6,910,176 (US)
10/10 3750 ft
(1.1 km)
11,538,240 (DS)
11,544,288 (US)
15/15 3000 ft
(0.9 km)
17,273,088 (DS)
17,279,808 (US)
