14
4.2 CONFIGURING DIP SWITCH S1
DIP switch S1 is where you configure the CopperLINK line. The following
tables describe the configuration for the 2168B.
5.0 OPERATION
Once the Model 2168Bs are properly installed, they should operate
transparently. No user settings required. This section describes reading
the LED status monitors.
5.1 POWER UP
Before applying power to the Model 2168B, please review section 3.3,
“Connecting Power” on page 12 to verify that the unit is connected to the
appropriate power source.
Table 1: 2168B Firmware Configuration
Position
S1-1 S1-2 S1-3 S1-4
Master/
Slave
Rate
ON Slave
(CPE)
4/1, 9/1, 16/2, 6/6, 10/10, 15/15
Rate Control (See table below).
OFF Master
(CO)
S1-2 S1-3 S1-4
Rate
(DS/US) *
*. DS = Downstream, US = Upstream
OFF OFF OFF 4/1
ON OFF OFF 9/1
OFF ON OFF 16/2
ON ON OFF 6/6
OFF OFF ON 10/10
ON ON ON 15/15
