SoundStation Premier
Installation Instructions and User's Guide
14
Extended Microphones
Size: 4.125 in 3 in 1in
Weight: 0.25 lb (0.10 Kg)
Cabling: Two-wire RJ9, 8ft
Environmental Requirements
Temperature: 5° - 40° C operating
Humidity:
20% - 85% non-condensing
Recommended Room Conditions
Reverberation time: < 0.4 seconds
Noise level:
< 48 dBA
Registration
UL, FCC, Industry Canada, CE
Audio Bandwidth
200 to 3500 Hz
Loudspeaker Volume
89 dBSPL
Network Interface
NORTEL ® Meridian ® , Meridian 1
(option 11 to 81), SL-1, or SL-100 digital PBX
SystemPower Requirements
90-110 VAC, 60 Hz.
Console
Power: 20 VDC, 800 mA
Size: 13.8 in 13 in 2.5 in
(35cm 33cm 6.4cm)
Weight: 2.0 lbs (0.9 Kg)
Interface Module
Power: 20 VDC, 150 mA
Size: 3.125 in 7.75 in 1.875 in
(7.9cm 19.7cm 4.8cm)
Weight: 0.75 lbs (0.34Kg)
Cable length to console:
25 ft (7.6m) to console
Cable length to telephone wall jack:
6 ft (1.8m)
RCA jack:
Line level to tape recorder
or Remote Lapel
Microphone
Specifications
