Quick Installation
Make sure the computer is turned off.
Attach the female end of the power cord (Indication A) to the adapter (Indication B), then
plug the adapter connector to the power “DC-IN (Indication D)” jack of the LCD monitor.
When using a power cord, plug the male end into the wall socket.
Plug one end of the signal cable (Indication C) in the “ANALOG” video signal connector
(Indication E) of LCD monitor
Turn on the computer.
Turn on the LCD monitor.
Before your operations of the monitor, please refer to P.7 “Operations” first.
A. Power Cord
B. Adaptor
C. Signal Cable
D. DC-IN
E. ANALOG
A
E
D
C
B
