Planar PL150 - Manual (Page 14)

13
E
N
G
L
I
S
H
Technical Data
Specifications
LCD Size 15.0" (full 15.0" viewable diagonal area)
Type TFT (Thin Film Transistor), Active Matrix Panel
Color 16.7M
Glass surface Anti-Glare
Input Signal Video RGB Analog
Video Sync Sync H. V. Separate Sync, H.V. Composite Sync
(TTL Compatible), Sync on Green,
H.F.: 30-62kHz, V.F.: 50-75Hz, Video Bandwidth: 80MHz
Compatibility PC Up to 1024 x 768
Macintosh® Power Macintosh® up to 1024 x 768
Resolution Primary Mode VESA 1024 x 768 @ 60Hz
Power Voltage AC100-240 VAC, 48-62Hz 12VDC Adapter
Connector Input Signal 15 pin D-sub
Display Area Full screen 304.1 mm (H) x 228.1 mm (V)
Operating Temperature 32 F to 104 F (0 ℃ to 40 ℃)
Conditions Humidity 10% to 90% (non-condensing)
Altitude to 10,000 feet
Storage Temperature -4 F to +140 F (-20 ℃ to +60 ℃)
Conditions Humidity 10% to 90% (non-condensing)
Altitude to 40,000 feet
Dimensions Physical 321.6 mm(H) x 338.4 mm(W) x 152.0 mm(D)
12.7" (H) x 13.3"(W) x 6.0"(D)
Package 425.0 mm(H) x 480.0 mm(W) x 132.0 mm(D)
16.7" (H) x 18.9"(W) x 5.2" (D)
Weight Net 3.25 kg (7.16 lbs)
Gross 4.90 kg (10.79 lbs)
Regulations Safety UL, cUL, TUV/GS, CB Report
EMI FCC DoC, CISPR 22 B, BSMI
Low Radiation MPR 1990:10, TCO99, PR EN50279
EMC CE
Energy Star EPA, NUTEK SEMKO Power Down, Energy 2000
Quality SEMKO Ergonomics, ISO 13406-2
Environment TCO99, TCO95(option)
Power saving On 35W (green LED) (Max.)
Off 3W (orange LED)
All products and trademarks are brand names of their respective companies.
Specifications are subject to change without prior notice.
