S P e C I F I C A T I O N S
AJ-HPX3700
AJ-HPX2700
General Specification
Power Supply
DC 12 V (11.0 V to 17.0 V)
Power Consumption
42 W
38 W
Temperature
Operating Temperature : 0°C to +40°C (32°F to +104°F) Keeping Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity
10% to 85 % (relative humidity)
Operating Time
approx. 120 min. (when using DIONIC90 battery)
Weight
approx. 4.9 kg (10.8 lbs, main unit only, excluding VF)
Dimensions (W x H x D)
137 mm x 209 mm x 318 mm (5-7/16" x 8-1/4" x 12-9/16", excluding handle and option slot cover)
Camera Section
CCD Elements
CCD x 3 (2/3 inch interline transfer type, 2,200,000 pixel)
CCD x 3 (2/3 inch interline transfer type, 1,000,000 pixel)
Video Format
RGB 3CCD
Total Picture Elements
2010 (H) x 1120 (V)
1370 (H) x 744 (V)
Effective Picture Elements
1920 (H) x 1080 (V)
1280 (H) x 720 (V)
Optical Filters
CC: 3200 K, 4300 K, 5600 K, 1/2 ND ND: CLEAR, 1/4 ND, 1/16 ND, 1/64 ND
Quantizing
14 bits
Horizontal Drive Frequncy
74.1758 MHz (59.94 Hz/23.98 Hz) , 74.25 MHz (50 Hz/24 Hz)
74.1758 MHz (59.94 Hz) , 74.25 MHz (50 Hz, 60 Hz)
Sampling Frequncy
74.1758 MHz (59.94 Hz/23.98 Hz) , 74.25 MHz (50 Hz/24 Hz)
74.1758 MHz (59.94 Hz) , 74.25 MHz (50 Hz, 60 Hz)
Digital Signal Process
74.1758 MHz (59.94 Hz/23.98 Hz) , 74.25 MHz (50 Hz/24 Hz)
74.1758 MHz (59.94 Hz) , 74.25 MHz (50 Hz, 60 Hz)
Programmable Gain
–3 dB, 0 dB, +3 dB, +6 dB, +9 dB, +12 dB, +15 dB, +18 dB, +21 dB, +24 dB, +27 dB, +30 dB
VFR
1 to 30 fps (1080/59.94i) ,1 to 25 fps (1080/50p)
1 to 60 fps (720/59.94p, 720/60p), 1 to 50 fps (720/50p)
Shutter Speed
1/50 (50 Hz) sec., 1/60 sec., 1/100 (59.94 Hz) sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., HALF
180 deg, 172.8 deg, 144 deg, 120 deg, 90 deg, 45 deg
Syncro Scan Sutter
1/61.7 sec. to 1/7200 sec. (1080/59.94i)
1/30.9 sec. to 1/3600 sec. (1080/29.97p)
1/24.7 sec. to 1/2880 sec. (1080/23.98p (A) )
1/51.4 sec. to 1/6000 sec. (1080/50i)
1/25.7 sec. to 1/3000 sec. (1080/25p)
1/61.7 sec. to 1/7200 sec. (1080/59.94i, 720/59.94p)
1/30.9 sec. to 1/3600 sec. (1080/29.97p, 720/29.97p)
1/24.7 sec. to 1/2880 sec. (1080/23.98p (A) , 1080/24p, 720/23.98p)
1/51.4 sec. to 1/6000 sec. (1080/50i, 720/50p)
1/25.7 sec. to 1/3000 sec. (1080/25p, 720/50p)
Lens Mount
2/3 inch bayonet mount
Optical System
F1.4 Prizm
Sensitivity
F10 (2000 lx, 3200 K, 89.9 % reflect, 1080/59.94i)
Minimum Luminance
2.48 lx (F 1.4, +30 dB) 0.042 lx (F 1.4, +30 dB, VFR=1 FRAME)
1.24 lx (F 1.4, +30 dB) 0.021 lx (F 1.4, +30 dB, VFR=1 FRAME)
Video S/N
54 dB (standard)
Registration
Less than 0.03 % (whole zone, without lens distortion)
Memory Card Recorder Section
Recording Format
AVC-Intra 100/AVC-Intra 50/DVCPRO HD Format switchable
Recording Video Signal
48 kHz/16 bits, 4CH
48 kHz/16 bits, 4CH (AVC-Intra/DVCPRO HD)
48.048 kHz/16 bits, 4CH (720/60p only)
Recording Media
P2 card
Recording Playback Time*
approx. 32 min. (when using 32GB P2card AJ-P2C032RG,
AVC-Intra 100 codec, recording in 1080/59.94p)
approx. 32 min. (when using 32GB P2card AJ-P2C032RG,
AVC-Intra 100 codec, recording in 1080/59.94p or 720/59.94p)
Digital Video
Sampling HD Frequncy
Y: 74.1758 MHz (59.94 Hz) /74.25 MHz (50 Hz) , P
B
/P
R
: 37.0879 MHz (59.94 Hz) /37.125 MHz (50 Hz)
Quantizing
AVC-Intra 100/AVC-Intra 50: 10 bits, DVCPRO HD: 8 bits
Video Compression
AVC-Intra 100/AVC-Intra 50: MPEG-4 AVC/H.264 Intra Profile, DVCPRO HD: DV-Bassed Comperssion (SMPTE370M)
Digital Audio
Quantizing
16 bits
Frequncy Response
20 Hz to 20 kHz ±1.0 dB (reference level)
Dynamic Range
More than 85 dB (1 kHz, AWTD)
Distortion
Within 0.1 % (1 kHz, reference level)
Headroom
18 dB/20 dB selectable
Input and Output
GENLOCK IN
BNC x 1, 1.0Vp-p, 75 Ω, (switchable to VIDEO IN or Return Video)
MONITOR OUT
BNC x1 (switchable to VBS/HD SDI) , VBS: 1.0 Vp-p, 75 Ω,
HD SDI: 0.8 Vp-p, 75 Ω (SMPTE292M/299M standards)
BNC x1 (switchable to VBS/HD SDI) , VBS: 1.0 Vp-p, 75 Ω,
HD SDI: 0.8 Vp-p, 75 Ω (SMPTE292M/296M standards)
HD SDI A OUT
BNC x1, 0.8 Vp-p, 75 Ω (SMPTE292M/299M/372M/352M standards) ,
with HD SDI B Dual Link
BNC x 1, 0.8 Vp-p, 75 Ω (SMPTE292M/296M standards)
HD SDI B OUT
BNC x1, 0.8 Vp-p, 75 Ω (SMPTE292M/299M/372M/352M standards) ,
with HD SDI A Dual Link
BNC x 1, 0.8 Vp-p, 75 Ω (SMPTE292M/296M standards)
TC IN
BNC x 1, 0.5Vp-p to 8 Vp-p, 10 kΩ
TC OUT
BNC x 1, low-impedance, 2.0 Vp-p±0.5 Vp-p
DVCPRO
—
6 pin (Output) , Transfer Speed: 400/200/100Mbps (selectable),
Transfer Data: IEEE 1394-1995/1394a-2000, IEC61883-1,2,
SPMTE396M standards, Control Command: AV/C Command Set standards
AUDIO IN
XLR 3 pin x 2 (CH1/CH2) , LINE/MIC/MIC+48 V switchable, LINE: –3 dBu /0 dBu /+4 dBu selectable
MIC : –60 dBu/–50 dBu selectable , MIC+48 V: Phantom +48 V, –60 dBu/–50 dBu selectable
MIC IN
XLR 5 pin x 1, –50 dBu/–40 dBu selectable , Phantom +48 V (ON/OFF)
WIRELESS IN
25 pin, D-SUB, –40 dBu
AUDIO OUT
XLR 5 pin x 1 (CH1/CH2) , –3 dBu/0 dBu/+4 dBu selectable , balanced, low-impedance
PHONES OUT
Stereo Mini Jack x 2
DC IN
XLR 4 pin x 1, DC12 V (11 V to 17 V)
DC OUT
4 pin, DC 12 V (11 V to 17 V) , Max.1.5A
LENS
12 pin
EVF
20 pin
RCU
10 pin for AJ-RC10G
GPS
6 pin for AJ-GPS910G
USB (2.0)
USB: 2.0, HOST: 4 pin Type-A , DEVICE: 4 pin Type-B
Monitor and Other packages
LCD Monitor
3.5 inches, LCD color monitor, 210,000 pixels
Supplied Accessories
Shoulder strap, Front audio volume knob (with screw), software CD-ROM
*Time shown above is when you record a series of 1 shot to P2 card. Depending on numbers of shots you record, time will get shorter than the number shown above.
Weight and dimensions shown are approximate. Specifications are subject to change without notice.
