Operating Instructions | 5
Wall Mounting
This unit can be mounted on a suitable wall or placed on a flat surface.
• Insert screws into wall. Avoid pipes and electrical cables etc. that may be
present/buried. The centre of the screws must be 71mm apart. Allow a protrusion of
2mm from the base of the screw head to the wall, using the washer provided (see
diagram below).
• Arrange the AC cord as shown, then mount the unit (4 possible routes available).
Connection
• Plug in the AC adaptor to the rear of the unit, and fasten the AC cord to prevent it
from being disconnected.
• The AC adaptor must remain connected at all times. (It is normal for the adaptor to
feel warm during use).
LED
Switch
Screw
Head
Washer
Wall
71mm
DC Jack
Cord from AC
adaptor
