Part identification chart – ProForm Recoil PFCCSY2926.1 User Manual

Page 5

Text mode
Original mode

M6 Washer (60)

M8 Washer (54)

M8 Nylon Locknut (57)

M10 Washer (59)

M10 Nylon Locknut (56)

M10 x 81mm Button Bolt (68)

M10 x 41mm

Button Bolt (71)

M8 x 100mm Button Bolt (70)

M4 x 12mm Flat

Head Screw (58)

M4 x 16mm

Screw (61)

M4 x 50mm Screw (66)

M6 x 76mm Screw (64)

M10 x 76mm Button Bolt (65)

M10 x 51mm Button Bolt (74)

M10 x 62mm Button Bolt (75)

M10 x 132mm Button Bolt (69)

M10 x 52mm Patch Screw (80)

PART IDENTIFICATION CHART

See the drawings below to identify small parts used in assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST on page 17.

Note: Some small parts may have been

pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
