- 8 -

.LAMP INDICATIONS

Red Flashing

Red Lit

Green Flashing quickly

Orange Lit

Orange Flashing

Charger is plugged into the AC outlet.

Ready to charge.
Now charging

Charging is completed.
Battery pack is warm. Charging will begin

when temperature of battery pack drops.
Charging is not possible. Clogged with

dust or malfunction of the battery pack.

. MAINTENANCE

Use only a dry, soft cloth for wiping the unit. Do not use a damp cloth, thinner, ben-

zine, or other volatile solvents for cleaning.

BATTERY RECYCLING

ATTENTION:

FOR Ni-MH Battery Packs, EY9200

A nickel metal hydride battery that is recyclable powers the product you have pur-

chased.

Please call 1-800-8-BATTERY for information on how to recycle this battery.

. TIGHTENING TORQUE

TIGHTENING TORQUE

The power required for tightening a bolt will vary, according to bolt material and

size, as well as the material being bolted. Choose the length of tightening time

accordingly.

Reference values are provided below.

(They may vary according to tightening conditions.)

Factors Affecting Tightening Torque

The tightening torque is affected by a wide variety of factors including the follow-

ings. After tightening, always check the torque with a torque wrench.

1) Voltage

When the battery pack becomes nearly discharged, the voltage decreases and the

tightening torque drops.
