ENGLISH 5
Legend of illustration (inside flap)
A) Front view
1 Power/standby button
Switches the SL300i off (to standby) and on.
– The indicator in the Power button lights up blue if the SL300i is on standby.
B) Rear view
2 Audio out 1
To connect the SL300i to the left and right audio inputs of your Audio system.
3
CVBS out
To connect the SL300i to the Composite video input of your TV.
4 S-video out
To connect the SL300i to the S-Video input of your TV.
5
Ethernet connector RJ-45
Optional Ethernet connection for a wired home network.
Use a CAT.5 shielded Ethernet cable (STP).
6 Audio Out 2
To connect the SL300i to the left and right audio inputs of your Audio system.
7 DC - in
For connecting the SL300i's power adapter.
– The indicator in the Power button lights up blue when the SL300i is connected to the
mains.
