Pelco DX2000 User Manual
Page 37

Pelco Manual C690M-E (11/04)
37
Deselecting a Recording Time
To deselect an individual time segment or range of segments, do the following:
1.
Click the Configuration button. Click Record Schedule. The screen (refer to Figure 12)
that appears displays seven days, each broken into half-hour segments.
2.
Do one of the following:
•
To deselect an individual time segment, just click the box to remove the check mark.
•
To deselect a range, click the check mark box for the starting time segment, hold
down the Shift and Ctrl keys, and then click the check mark box for the ending time
segment.
