UNASSEMBLED PARTS

Steering Wheel

(1) Knob

(1) Washer
17/32 x 1-3/16 x 12 Gauge

Seat

(2) Keys

Slope Sheet

Keys

Steering

Wheel Insert

Mower

Gauge Wheel

(2) Hex Bolts 5/16-18 x 1

(2) Washers

17/32 x 7/8 x 16 Ga.

(2) Locknuts

5/16-18

Nose Roller

Nose Roller

Nose Roller
Brackets

Steering

Wheel Adapter

Steering Sleeve

Steering Sleeve

Extension

(1) Oil Drain Tube
For Future Use

(4) Washers

3/8 x 3/4 x 14 Ga.

(4) Wheels

(4) Adjusting Bar

(4) Retainer Springs

(double loop)

(4) Clevis Pins

(4) Locknut 3/8-16

(4) Shoulder Bolt

(1)Front Plate
Assembly

(5) Retainer Springs

(double loop)

(2) Retainer Springs (single loop)

(2)Flanged
Pins
