Planar PE2010 - Manual (Page 15)

15
OPERATING INSTRUCTIONS (cont.)
ADJUSTING THE PICTURE
The descriptions for function control LEDS
Main
Menu
Item Main
Menu
Icon Sub Menu
Item Sub
Menu
Icon
Description
Reset Value
Contrast Contrast from Digital-
register. Recall Warm
Contrast Value
Luminance
Brightness Backlight Adjustment Recall Warm
Brightness
Value
Focus Adjust Picture Phase
to reduce Horizontal-
Line noise Do Auto
Config
Setup
Clock Adjust picture Clock to
reduce Vertical-Line
noise. Do Auto
Config
H. Position Adjust the horizontal
position of the picture. Do Auto
Config
Position
V. Position Adjust the
verticalposition of the
picture. Do Auto
Config
C1 N/A Recall Warm
Temperature from
EEPROM
C2 N/A Recall Warm
Temperature from
EEPROM.
sRGB N/A Recall sRGB
Temperature from
EEPROM.
Red Gain from Digital-
register.
Green Gain Digital-
register.
Color
Temp.
User
Blue Gain from Digital-
register.
The User
R/G/B
value(default
is 100) will not
be Modified by
Reset
function.
