Specifications
Tuning System Frequency synthesized 100 Position ( 0 to 99 ).
RF Channels VHF 0 to 12 PAL B
UHF 21 to 69 PAL G
S’1 to S’3 HYPER TUNER
S1 to S41
Receiving Systems 1. PAL B/G Reception of Off air broadcasts
Playback from Video Tape Recorders
2. NTSC 4.43 Playback from Special Video Tape
3. NTSC 3.58 Recorders and Special Video Disc Players
4. PAL 60Hz (Via the AV Sockets) only.
Power Requirements 220 ~ 240Volts + 10% 50Hz
Power Consumption TX-86PW100A 228W Max 3W Stand-By
TX-76PW100A & TX-76PW50A 211W Max 3W Stand-By
Chassis EURO7
Picture Tube TX-86PW100A 86cm Viewable (Measured diagonally)
TX-76PW100A & TX-76PW50A 76cm Viewable (Measured diagonally)
Audio Output Two Way Four Speakers Plus Woofer (10W + 10W + 12W)
External Speaker TX-86PW100A & TX-76PW100A 10W x Four Speakers (Not supplied)
Connections
Headphone Socket TX-86PW100A & TX-76PW100A 3.5mm Stereo (Main and Sub)
TX-76PW50A
3.5mm Stereo (Main)
Aerial Impedance 75
?
Unbalanced coaxial
Component Video TX-86PW100A & TX-76PW100A 1080i and 576P
TX-76PW50A
576P
Video / Audio Terminals AV1 IN (Rear) : S-Video, Video, Audio L/R Terminals
AV2 IN (Rear) : Video or Y/P
B
/P
R
, Audio L/R Terminals
AV3 IN (Front) : S-Video, Video, Audio L/R Terminals
AV4 IN (Rear) : Video or Y/P
B
/P
R
, Audio L/R Terminals
Digital Audio input TX-86PW100A & TX-76PW100A coaxial, optical
Video / Audio Input S-Video Y: 1.0Vp-p 75
?
C: 0.3Vp-p 75
?
Video in 1.0Vp-p, 75
?
Audio in Approx. 400mV 1k
?
Monitor Out Video Out 1.0Vp-p, 75
? ?
Audio Out Approx. 400mV 1k
?
Accessories Supplied Remote Control EUR511229
2 Type ‘AA’ Batteries
Instruction Manual TQB4A0152
Dimensions w d h Weight
TX-86PW100A 92.6cm 65.1cm 58.4cm 86kg
TX-76PW100A & TX-76PW50A 82.7cm 53.5cm 57.9cm 60kg
Note:
Design and Specifications are subject to change without notice. Weight and Dimensions shown are approximate.
