Quick Start
Guide
Basic Connection (Antenna +
TV)
Before
Connection
To connect antenna terminals
ANT OUT ANT IN
2 1 AV IN
ANTENNA
Cable In
Basic Connection
Connecting Antenna (To watch TV) Example 1
(If no Cable Box)
•
If using Cable Box
•
Set the TV channel to CH3 or CH4.
AC Cord
(Connect after all the
other connections.)
Cable TV
VHF/UHF Antenna
TV
Back of the TV
Cable TV
AC 120 V
60 Hz
VHF/UHF Antenna
Cable Box
Note
•
When disconnecting the power cord, be absolutely sure to disconnect the power cord plug from the wall outlet first. •
For additional assistance, visit us at: www.panasonic.com
www.panasonic.ca
or
or
Antenna
terminal
