-3- -6-
.
Part 3-Attaching brackets to screen
Center brackets vertically on back of screen. Select the
Attach brackets to screen using four selected
screws and four square washers(E) at the top and bottom of each bracket.
small(A),medium
(B or C) or large(D) screws.
Tighten screws firmly. Do not overtighten
Part 3-Attaching brackets to screen
A-D
E
Square washer(E)
Small hole for
M4 screws
Medium hole for
M5 and M6 screws
Large hole for
M8 screws
Wood stud
Stud finder
2 50mm) ” (
Φ3/16 (5mm) ”
Part 1a-Wood Stud Mounting
.
Use wall plate(1) as a template, make sure it is level, and mark four mounting
holes along the center lines of the wood studs. Drill four 3/16
) ) . .
”
”
(5mm)dia
holes 2 (50mm) deep. Level wall plate(1) and attach to wall with four long
bolts(G and four washers(F . Tighten screws firmly Do not overtighten
Part 1a-Wood Stud Mounting
G
F
Magnetic removable
bubble level
