13
WCS-SIF-01
Training & Maintenance Manual
Pneumatic
Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
Ordering Information
Model Number Index – Generation 3.0
Valve Series
H2 Size ISO 5599- Valves
Basic Series
S3 Serial
Generation 3.0
Options
0 None
Protocol
D DeviceNet TM
Manifold /
Subbase Stations
1 1 - Station Manifold
2 - Station Manifold
5 Single Subbase
Basic Valve Manifold / Engineering
Series Series Protocol Subbase Stations Power I/O Options Level
S3 H2 D 2 D 0 C
Engineering Level
C Current
Power I/O
A In / 4 Out, Bus Power 1
B In / 4 Out, Ext. Power 1
C 4 In / 4 Out, Bus Power 1,3
D 4 In / 4 Out, Ext Power 1,3
E Subbase, Bus Power
F Subbase, Ext. Power
Notes:
1. Not available with single subbase option.
. inputs come standard with subbase or manifold options.
3. additional auxiliary inputs can be ordered by selecting this option.
