PARAMOUNT PARTS LIST
R
PARTS LIST
r
Replaces
4
Note: Illustration may differ from actual model due to design changes
PARTS LIST NO.
PAGE NO.
MODEL(s)
545014364
PP446ET
DATE
2/10/09
545014364 --- 6/06/08
11
7
8
9
10
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must
be performed by qualified
service personnel.
WARNING
=
NEW PART NUMBER FOR THIS IPL
n
=
REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
Ref.
Part No.
Description
1.
530071788
Kit--Lower Shaft Assy.
(Incl. flex shaft)
2.
530071802
Kit--Shield Assy.
(Incl. 3,4,5,6)
3.
530052286
Limiter--Line
4.
530015814
Screw
5.
530015820
Bolt
6.
530016152
Wingnut
7.
530095776
Assy--Hub/Arbor
8.
530053241
Spring--Return
9.
530401957
Retainer--Spool
10.
952711624
Accy--Wound Spool
11.
952711630
Accy--Cutting Head
(Incl. 7--10)
545209101
Decal--Lower Shaft Warning
3
2
1
5
6
4
Not Shown
TYPE 1,2,3
