Functional Overview
Front and Rear Panels
Mains Cord
– connect to power outlet
Video out (Y C B C R )
– connect to a TV with component video
inputs
Video out (CVBS)
– connect to a TV with CVBS inputs
AUDIO OUT (Left/Right)
– connect to AUDIO inputs of an
amplifier, receiver or stereo system
POWER ON/OFF
– switches the player On or Off
Disc Tray
B; PLAY/PAUSE
– star ts/interr upts playback
9 STOP
– stops playback
/ OPEN/CLOSE
– opens/closes the disc tr ay
DISPLAY
– shows the current status of the player
MIC socket 2 for karaoke
MIC socket 1 for karaoke
MIC volume control 1 for karaoke
MIC volume control 2 for karaoke
Video out (S-Video)
– connect to a TV with S-Video inputs
Optical & Coaxial output
– connect to a receiver with optical & coaxial inputs
Caution: Do not touch the inner pins of the jacks on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
