Connections
(continued)
11
Connect a Camcorder
Audio
cable
Video
cable
How to connect:
Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and camcorder.
To playback Camcorder
1. Turn on your LCD, press Source button on the remote control.
2. Press Source button repeatedly to select AV1.
3. Turn on your camcorder and set it to output mode. (For details, refer to
your camcorder owner's manual.)
4. Insert the tape into the camcorder and press Play button.
Note:
The operations of the camcorder may be different and is dependent on your
model. Please read the owner's manual of your camcorder to confirm operation.
Yellow (VIDEO)
White (AUDIO L/MONO)
Red (AUDIO R)
ANTENNA INPUT
HEADPHONE
AV1 INPUT/
S-VIDEO IN
AV2 INPUTS
AV OUT
