Connecting up 02
13
En
Chapter 2
Connecting up
• Before making or changing any rear panel
connections, make sure that all the
components are switched off and
unplugged from the power supply.
• CAUTION: These speaker terminals can
be under HAZARDOUS VOLTAGE . When
you connect or disconnect the speaker
cables, to prevent the risk of electric
shock, do not touch uninsulated parts
before disconnecting the power cord.
(H047 En)
Connecting the speakers
AUDIO
P B Y
ONENT VIDEO OUT
LINE 2
COAXIAL IN
CENTER SUB
WOOFER L R L R
FRONT SURROUND
S-VIDEO
OUT
VIDEO
OUT
SPEAKERS
Front right
Surround right
XV-HTD 330
Surround left
Front left
Subwoofer
Center
Gray Blue
White Red
Purple
Green
