PDK-WM02 Wall Bracket
NEW
NEW
NEW
NEW
NEW NEW
PDA-H05
17
Swivel Table Top Stand PDK-TS12
NEW
For 43-inch and 50-inch only
577 mm
380 mm
249.5 mm
Table Top Stand PDK-TS10
For 43-inch and 50-inch only
566 mm
325 mm
491 mm
Conventional Long System Cable
(10 m) PDA-H03
Optical Long System Cable
(30 m)
PDP-S37
PDP-S38 Side-mounted Speakers
PDP-S39
Under-mounted Speaker
For 43-inch only
Floating Floor Stand
For 43-inch and 50-inch only
PDK-FS05
760 mm
478 mm
960 mm
Angled Wall Bracket
For 43-inch and 50-inch only
* With under-mounted speakers, the angle options are limited.
PDK-WT02 *
Floor Stand
For 43-inch and 50-inch only
PDK-FS06
784 mm
476 mm 701 mm
For 43-inch and 50-inch only
576 mm
475 mm
Depth = 32 mm
Dimensions (W x H x D): 1076 x 83 x 92 mm
PDP-S37 for 43-inch only
PDP-S38 for 50-inch only
Dimensions (W x H x D): PDP-S37 = 76.5 x 632 x 92 mm
PDP-S38 = 76.5 x 717 x 92 mm
See page 81 for connection example.
For full features and specifications, please see page 82.
