Display controls – Planar ND1950 User Manual
Page 9
7
Display Controls
User Controls
A brief description and the location of all Network Display functions controls and indicators:
5 4
1
3 2
Figure 2-1
1
Power Control - LED
Modes are changed by pressing the Power Control Button (Please refer to
Figure 2-2)
2
Brightness Function / Adjust increase
3
Brightness Function / Adjust decrease
4
Audio Volume Function / Adjust increase
5
Audio Volume Function / Adjust decrease
