Planar ND1950 - Manual (Page 12)

10
External Connections
Power Input (DC input) DC Socket, 12V, 5A (Center Positive)
GigaBit Ethernet port RJ45
USB ports
4 x USB connectors, Type A Receptacles
Headphone 3.5mm Stereo Jack
Microphone 3.5mm Mono Jack, Pink
Headset RJ22 (4P4C, Reserved for Future VOIP Software Support)
Environment
Operating Condition:
Storage Condition: Temperature
Relative Humidity
Temperature
Relative Humidity 5°C to 40°C/41°F to 104°F
20% to 80%
-20°C to 60° C/-4°F to140° F
5% to 85%
Power Supply (AC Input)
Input Voltage Single phase, 100 ~ 240VAC, 50 / 60 Hz
Input Current
1.5 A maximum
Size and Weight ND1750 ND1950
Dimensions 367 (W) x 384 (H) x 199 (D) mm 413 (W) x 418 (H) x 222 (D) mm
Net Weight 4.5 kg 4.6 kg
Gross Weight 7.7 kg 8.0 kg
Supported Display Resolutions
If the selected timing is NOT included in table below, the Network Display will use the most suitable available timing.
Mode Resolution
(Horizontal X Vertical)
SXGA 1280 X 1024
XGA 1024 X 768
SVGA 800 X 600
VGA 640 X 480
