KBX-RP-09
ITEM
NO.
PART NO.
DESCRIPTION
MODEL NO.
HEAT EXCHANGER ASSEMBLY
1
HEX3081
HEAT EXCHANGER
KBN399
1
HEX3082
HEAT EXCHANGER
KBN500
1
HEX3088
HEAT EXCHANGER
KBN600
1
HEX3089
HEAT EXCHANGER
KBN700
1
HEX3090
HEAT EXCHANGER
KBN800
CONTROLS
2
RLY2202
LOW VOLTAGE CONNECTION BOARD
ALL
3
RLY30018
INTEGRATED CONTROL
KBN399
3
RLY30013
INTEGRATED CONTROL
KBN500
3
RLY30017
INTEGRATED CONTROL
KBN600 - 800
3
RLY30020
HIGH ALTITUDE INTEGRATED CONTROL
KBN399
3
RLY30021
HIGH ALTITUDE INTEGRATED CONTROL
KBN500
3
RLY30022
HIGH ALTITUDE INTEGRATED CONTROL
KBN600 - 800
4
RLY2210
USER INTERFACE CONTROL
ALL
5
RLY2085
RELAY BOARD, 1.5 HP PUMP
ALL
6
TST2032
INLET / OUTLET SENSOR
ALL
7
TST2044
BULBWELL, INLET / OUTLET SENSOR
ALL
8
HLC2510
HIGH LIMIT (BEFORE SERIAL C08)
KBN399/500
8
HLC2702
MANUAL RESET HIGH LIMIT (AFTER SERIAL C08 FOR KBN399/500)
ALL
9
RLV30000
AIR VENT VALVE
ALL
10
FAN3035
FAN ASSEMBLY
KBN399
10
FAN3034
FAN ASSEMBLY (BEFORE SERIAL J07)
KBN500
10
FAN3037
FAN ASSEMBLY (AFTER SERIAL J07)
KBN500
10
FAN3038
FAN ASSEMBLY (PRIOR TO SERIAL C09)
KBN600-800
10
FAN30001
FAN ASSEMBLY (BEGINNING SERIAL C09)
KBN600-800
11
GKT2436
BLOWER / AIR ARM GASKET
KBN399
11
GKT2438
BLOWER / AIR ARM GASKET
KBN500
12
GKT2034
BLOWER / AIR ARM GASKET (BEFORE SERIAL J07 FOR KBN500)
KBN500-800
GAS VALVES
13
VAL3204
GAS VALVE ASSEMBLY
KBN399
13
VAL3206
GAS VALVE ASSEMBLY NAT (BEFORE SERIAL J07)
KBN500
13
VAL3207
GAS VALVE ASSEMBLY NAT (AFTER SERIAL J07)
KBN500
13
VAL3212
GAS VALVE ASSEMBLY NAT
KBN600
13
VAL30006
GAS VALVE ASSEMBLY NAT
KBN700
13
VAL3213
GAS VALVE ASSEMBLY NAT
KBN800
13
VAL30010
GAS VALVE ASSEMBLY LP (BEFORE SERIAL J07)
KBL500
13
VAL30011
GAS VALVE ASSEMBLY LP (AFTER SERIAL J07)
KBL500
13
VAL30012
GAS VALVE ASSEMBLY LP
KBL600
13
VAL30013
GAS VALVE ASSEMBLY LP
KBL700
13
VAL30014
GAS VALVE ASSEMBLY LP
KBL800
14
GKT2050
GAS VALVE GASKET
KBN600-800
15
GAC2029
GAS CUT OFF VALVE 1X1 (BEFORE SERIAL J07)
KBN500
15
GAC2029
GAS CUT OFF VALVE 1X1
KBN399,600-800
16
GAC2028
GAS CUT OFF VALVE 3/4 X 3/4 (AFTER SERIAL J07)
KBN500
17
GKT2444
GASKET, VENTURI
KBN399
17
GKT2080
AIR SHROUD GASKET (AFTER SERIAL J07)
KBN500
17
GKT2049
GASKET, VENTURI
KBN600-800
18
MSC3185
AIR INLET KIT
KBN399
18
MSC3187
AIR INLET KIT (AFTER SERIAL J07)
KBN500
18
MSC3186
AIR INLET KIT (BEFORE SERIAL J07 FOR KBN500)
KBN500-800
PLEASE HAVE SERIAL NUMBER AVAILABLE WHEN ORDERING PARTS.
