A-1 INSTALLATION
V160-S
A-1
Input Circuit
115V (20A Plug and Branch)
115V (30A Branch)
230V (30A Branch)
230V (30A Branch)
Maximum Open Circuit Voltage
48 Volts Max.
Duty Cycle
100%
35%
100%
Output Current Range
5-160 Amps
INPUT - SINGLE PHASE ONLY
RATED OUTPUT
OUTPUT
Height Width Depth Weight
12.6 in. 7.9 in. 16.9 in. Approx. 24.2lbs.
320 mm 200 mm 430 mm 11 kgs.
PHYSICAL DIMENSIONS
TEMPERATURE RANGES
OPERATING TEMPERATURE RANGE
-20°C to +40°C
STORAGE TEMPERATURE RANGE
-50°C to +85°C
RECOMMENDED INPUT WIRE AND FUSE SIZES FOR MAXIMUM RATED OUTPUT
INPUT VOLTAGE /
FREQUENCY (HZ)
230/50/60
MAXIMUM TIME-DELAY CIRCUIT
BREAKER OR FUSE SIZE (AMPS)
30
TYPE S, SO ST, STO, OR EXTRA
HARD USAGE INPUT CORD AWG
#12
Input Voltages / 50 /60 Hz.
115 V (20 A Plug and branch)
115 V (30 A branch)
230 V
Max. Input Current at rated Output
20 A
25 A
34 A
Output Amps
60 (Stick)
90 (TIG)
80 (Stick)
110 (TIG)
160 (Stick)
160 (TIG)
130 (Stick)
130 (TIG)
Output Volts
22.4
13.6
23.2
14.4
26.4
16.4
25.2
15.2
Type of Output
DC
TECHNICAL SPECIFICATION V160-S
