Signature utility bench – Life Fitness Utility Bench User Manual
Page 6
Item
1
2
3
4
5
6
7
8
9
Qty
1
1
2
8
2
1
4
1
6
Tools Required:
O
17mm Wrench
O
Metric Allen Wrench Set
O
Ratchet with 17mm Socket
O
Rubber Mallet
O
Ratchet Extension
Description
Seat Frame
Base Frame
M10 x 25mm Bolt
3/8” Flat Washer
M10 Nylock Nut
Seat Pad
M10 x 35mm Bolt
Back Pad
1” Hole Plug
Part Number
78414XX
78411XX
3256202
3102514
3242002
7813801
3256204
7468901
3237403
Signature Utility Bench
Assembly Instructions
