8
10
9
7
6
5
4
3
2
1
11
3
3
3
Page 7
BACK FRAME ASSEMBLY - 7678201 ________________________________________
PLLHP PLATE LOADED LINEAR HACK PRESS
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7678301 WLDMT, PLLHP BACK FRM BX
2 2 7444601 BUMBER, DONUT
3 12 3237404 PLUG, 9/16" HOLE
4 2 7760201 ASSY, WEIGHT HORN
5 4 3239313 1/2-13 X 3.25 UNS HEX FHB G5 ZN
6 4 3102507 WASHER, TYPE A PLAIN
7 4 3102801 NUT, NYLOCK 1/2-13 ST ZN
8 4 H-BACK-WASH Backing Washer
9 1 7422004 LABEL, 2" ASTM WARN
10 1 M051-00299-A000 HAMMER PATENT DECAL
11 1 7571302 LABEL, SERIAL NUMBER HAMMER
