3
ITEM PART DESCRIPTION MODEL
NO. NO. NO.
Gas Train Assemblies
1 KIT # BNR2404: BNR3501: BNR3502: BNR2404 is Main Burner
BNR3410 990 9ea. 1ea. 1ea.
BNR3411 1260 12ea. 1ea. 1ea. BNR3501 is Main Burner Connected
BNR3412 1440 14ea. 1ea. 1ea. Thermocouple Compression Fitting
BNR3413 1800 17ea. 1ea. 2ea.
BNR3414 2070 20ea. 1ea. 2ea. BNR3502 is Main Burner w/ Pressure
Tap, Barbed Fitting
4 ORF2413 ORIFICE, NAT. ALL
4 ORF2405 ORIFICE, LPG. ALL
5 VAL3403 VALVE, GAS NAT. ALL
5 VAL3404 VALVE, GAS LPG. ALL
Controls & Gauges
6 HLC2701 HIGH LIMIT CF
6 HLC2702 HIGH LIMIT MANUAL RESET CH
-- MSC2420 TERMINAL STRIP 6 POLE ALL
-- MSC2447 CIRCUIT BREAKER 7 AMP. ALL
7 PAN3000 CONTROL PANEL COMPLETE ALL
8 PAN3001 LIGHT ASSEMBLY W/FRONT ESCUTCHEON ALL
-- MSC2448 LIGHT, INDICATOR 120V. ALL
-- MSC2449 LIGHT, INDICATOR 28V. ALL
9 RLY3002 IGNITION MODULE ALL
10 RLY3003 TIME DELAY MODULE ALL
11 TST3004 ELECTRONIC THERMOSTAT CONTROL ALL
11 TST3006 ELECT. THERMOSTAT CONTROL, W/INDOOR/OUTDOOR SENSORS OPTIONAL
-- WRE2416 SENSOR ALL
-- HLC2503 110º HI LIMIT (POOL PIPING) CP
-- HLC2501 200º HI LIMIT (OUTLET SIDE) BEGINNING SERIAL # A980000
12 PLT3400 HOT SURFACE IGNITOR ALL
13 PRS2416 PRESSURE SWITCH, DUAL ALL
14 PRS2417 PRESSURE SWITCH, LOW AIR ALL
-- PRS2406 PRESSURE SWITCH, POOL HEATER CP
15 TRF2701 TRANSFORMER 150V.A. ALL
-- WTR2041 SWITCH, FLOW OUTDOOR CF/CH
-- MSC2426 SWITCH, MAIN POWER ALL
-- MSC2706 TUBING, EDPM 1/4" (ORDER BY THE FOOT) ALL
-- MSC2461 TUBING, SILICONE (ORDER BY THE FOOT) ALL
-- MSC2406 TUBING, EDPM 1/8" (ORDER BY THE FOOT) ALL
Heat Exchangers
16 GKT2418 GASKET, HEAT SHIELD ALL
17 HEX3420 HEAT EXCHANGER H (CF & CP before serial F00 & All CH) 990
17 HEX3421 HEAT EXCHANGER H (CF & CP before serial F00 & All CH) 1260
17 HEX3422 HEAT EXCHANGER H (CF & CP before serial F00 & All CH) 1440
17 HEX3423 HEAT EXCHANGER H (CF & CP before serial F00 & All CH) 1800
17 HEX3424 HEAT EXCHANGER H (CF & CP before serial F00 & All CH) 2070
17 HEX3000 HEAT EXCHANGER HLW (After Serial # F00) CF/CP990
17 HEX3001 HEAT EXCHANGER HLW (After Serial # F00) CF/CP1260
17 HEX3002 HEAT EXCHANGER HLW (After Serial # F00) CF/CP1440
17 HEX3003 HEAT EXCHANGER HLW (After Serial # F00) CF/CP1800
17 HEX3004 HEAT EXCHANGER HLW (After Serial # F00) CF/CP2070
18 JKE6078 V-BAFFLE (9 PER UNIT) 990
18 JKE6079 V-BAFFLE (9 PER UNIT) 1260
18 JKE6080 V-BAFFLE (9 PER UNIT) 1440
18 JKE6081 V-BAFFLE (9 PER UNIT) 1800
18 JKE6082 V-BAFFLE (9 PER UNIT) 2070
35 JKE6159 V-BAFFLE FRAME RUNNER 990
35 JKE6160 V-BAFFLE FRAME RUNNER 1260
35 JKE6161 V-BAFFLE FRAME RUNNER 1440
35 JKE6162 V-BAFFLE FRAME RUNNER 1800
35 JKE6163 V-BAFFLE FRAME RUNNER 2070
36 JKD6187 V-BAFFLE FRAME END ALL
* "CONSULT FACTORY"
NOTE: CH = BOILER, CF = WATER HEATER & CP = POOL HEATER
